American Standard® · Technical Data Sheet
Elevate 48x30-inch Curved Shower Base with Center Drain Outlet
The American Standard Elevate 48x30-inch Curved Shower Base with Center Drain Outlet shower base provides lasting, reliable performance with a non-porous, easy-clean surface and low 1-inch threshold for safe, comfortable access. Backed by a 10-year warranty.
Specifications
| Model / Order # | A8015T-CO |
|---|---|
| Collection | Elevate |
| Family | ELEVATE |
| Series | SMC |
| Material | Acrylic |
| Color | Arctic |
| Installation Type | Floor |
| Shape | Rectangular |
| Country of Origin | United States |
| Residential Warranty | 10-year |
| Commercial Warranty | 10-year |
| Availability | Ships 1-3 Business Days |
Dimensions & Capacity
| Nominal Length | 48 in |
|---|---|
| Nominal Width | 30 in |
| Nominal Height | 2.75 in |
| Drain Position | Center |
| Drain Size | 2 in |
| Drain Included | No |
Dimensional Drawing
From the official spec sheet. Open the full PDF for all pages and rough-in detail.
Features & Benefits
- Durable design — Premium StruXure® material resists peeling & chipping
- No-slip floor — Textured surface for added protection from slipping
- Perfect fit — Versatile curved design works for 30”- 36” alcoves
- 10-year warranty — Your assurance of quality construction and lasting beauty
- Dimensions – 48” x 30” x 2 ¾”; please refer to specification sheet for exact dimensions and installation information
- Complete your shower - Elevate curved barn-style doors (AM00839400) are exclusively designed to fit your Elevate base. Consider finishing your shower with your favorite tile or the Elevate Subway Tile Patterned Wall System (2947SWT48.011). Both sold separately.
- *Maximum weight support of 300 lbs. without mortar
- Perfect fit — Versatile curved design works for 30”- 36” alcoves
- 10-year warranty — Your assurance of quality construction and lasting beauty
Packaging & Shipping
| Ship Method | LTL |
|---|---|
| Shipping Group | FREIGHT |
| Shipping Weight | 60 lbs |
| Shipping Length | 49.5 in |
| Shipping Width | 35.125 in |
| Shipping Height | 4.375 in |
| Cartons | 1 |
| Pieces | 1 |
| Packaging Volume | 2.29 ft³ (0.06 m³) |
| Full-Truckload Qty | 300 |
| Stackable | No |
Installation
Items required for installation
Base and Drain
Documents & Downloads
Certifications & Compliance
IAPMO ListedCSAMade in USA
Project Information & Notes
Project:
Contractor:
Representative:
Date:
Tel:
Notes:
10-year residential warranty · 10-year commercial.
Questions, samples, or project pricing? Contact your American Standard sales rep.
Specifications subject to change without notice. Confirm current dimensions and certifications on the product page before specifying. © American Standard Bathing.
