American Standard® · Technical Data Sheet
Elevate Framed 74-inch Neo-Angle Pivot Shower Door
The American Standard Elevate Framed 74-inch Neo-Angle Pivot Shower Door delivers quality construction and reliable performance with 1/4-inch (6 mm) safety-tempered clear glass. The pivot hinge provides smooth, dependable swing operation. Backed by a 10-year warranty.
Specifications
| Model / Order # | AM00841400 |
|---|---|
| Collection | Elevate |
| Family | ELEVATE |
| Series | AS SHOWER DOORS |
| Material | Glass |
| Finish / Color | Brushed Nickel |
| Door Type | Bypass |
| Frame Type | Semi-Frameless |
| Glass Pattern | Clear |
| Country of Origin | China |
| Residential Warranty | 10-year |
| Commercial Warranty | 10-year |
| Availability | Ships Free - in 2-3 weeks |
Dimensions & Capacity
| Nominal Length | 36.25 in |
|---|---|
| Nominal Width | 38 in |
| Nominal Height | 74 in |
| Glass Thickness | 0.25 in |
| Min. Walk-Through Opening | 26.625 in |
| Drain Included | No |
Dimensional Drawing
From the official spec sheet. Open the full PDF for all pages and rough-in detail.
Features & Benefits
- Semi-frameless construction: minimal metal framing on outer edges provides structural support while maintaining a clean, open look
- Safety-tempered glass: 1/4-inch (6 mm) tempered clear glass meets ANSI Z97.1 safety standards for shatter resistance
- Pivot hinge design: full-length pivot hinge delivers smooth, reliable door swing and long-lasting operation
- Generous dimensions: 36.25 x 73.5-inch width x height fits standard shower openings
- Crystal-clear glass: water-clear transparency showcases tile work and creates an open, airy feel in the bathroom
- Reversible hinge: door can be configured to open left or right to accommodate any bathroom layout
- Clean profile: minimal hardware elements keep the enclosure looking streamlined and easy to maintain
- Precision manufacturing: components are factory-engineered to fit standard rough openings with minimal field adjustment
- Quality hardware: durable handles and hinges are engineered for thousands of open-and-close cycles
Packaging & Shipping
| Ship Method | LTL |
|---|---|
| Shipping Group | FREIGHT |
| Shipping Weight | 112 lbs |
| Shipping Length | 26.937 in |
| Shipping Width | 3.938 in |
| Shipping Height | 76.75 in |
| Cartons | 1 |
| Packaging Volume | 4.71 ft³ (0.13 m³) |
| Stackable | No |
Documents & Downloads
Project Information & Notes
Project:
Contractor:
Representative:
Date:
Tel:
Notes:
10-year residential warranty · 10-year commercial.
Questions, samples, or project pricing? Contact your American Standard sales rep.
Specifications subject to change without notice. Confirm current dimensions and certifications on the product page before specifying. © American Standard Bathing.
